USED BENZ--ZOOMLION Concrete Pump Truck 49m
- Condition:
- Used
- Year of manufacture:
- 2015
- Emission:
- Euro IV
- Length of Pump:
- 49m
- Worked time:
- 500 hours
Related products
| Basic Specification | |
| Brand of Pump | Zoomlion |
| Length of Pump | 49m |
| Year of manufacture | 2015 |
| Condition | Used |
| Worked time | 500 hours |
| Maximum theoretical throughput | 180/120m3/h |
| Maximum outlet pressure of concrete | 8.3/12MPa |
| Pumping frequency | 26/18 times/min |
| Bore X Stroke of Concrete | 260x2100mm |
| Structural style | 49X-6RZ |
| Max Placing (height/radius/depth) | 49/44/35m |
| Rotation angle | ±270° |
| Model of chassis | Benz ACTROS 3341 6x4 |
| Max power of engine | 300/1800KW (r/min) |
| Emission | Euro IV |
| Item | Parameter | ||
| Outline dimensions (Length′ Width ′Height)mm | 12020×2500×4000 | ||
| Fuel type | Diesel | ||
| Engine emission standard | Euro IV | ||
| Displacement/L Powerml/kw | 11.95/300 | ||
| Steering type | Steering wheel | ||
| No. of axle | 3 | ||
| Wheel base(mm) | 4500+1350 | ||
| No. of spring leaf (front/rear) | 2+3/9 | ||
| Tire | 12.00R20 | ||
| Track (front/rear) mm | 2029/1872 | ||
| No. of tire (exclude spare tire) | 12 | ||
| Total vehiclecurb weight | Total weight(kg) | 33500.00 | |
| Front axle load(kg) | 13500.00 | ||
| Mid, rear axle load(kg) | 20000.00 | ||
| Total weight | Total weight(kg) | 34000.00 | |
| Front axle load(kg) | 14000.00 | ||
| Mid, rear axle load(kg) | 20000.00 | ||
| Crew in cab | 2 | ||
| Approach angle/Departure angle | 20°/12° | ||
| Front overhang /Rear overhang(mm) | 1360/3500 | ||
| Max. speedkm/h | 85 | ||
| Min. ground clearance(mm) | 270 | ||
| Max. grade-ability | 38% | ||
| Fuel consumption of 100km(L/100km) | 40 | ||
| Chassis | Model | ACTROS 3341 | |
| Drive mode | 6X4 | ||
| Manufacturer | BENZ | ||
| Engine | Model | OM501LA | |
| Manufacturer | BENZ | ||
Trade Terms:
Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.
